CEEG
400w Solar Panel Kit - Accept Customizable
400w Solar Panel Kit - Accept Customizable
|
Electrical Characteristics at Standard Test Conditions (STC)
|
|||
|
Module Type
|
CSUN450-144M
|
CSUN455-144M
|
CSUN460-144M
|
|
Maximum Power (Pmpp)[W]
|
450
|
455
|
460
|
|
Positive Power Tolerance[W]
|
0-5
|
0-5
|
0-5
|
|
Open Circuit Voltage (Voc)[V]
|
49.3
|
49.5
|
49.7
|
|
Maximum Power Voltage
(Vmpp)[V] |
41.4
|
41.6
|
41.8
|
|
Maximum Power Current(Impp)[A]
|
10.88
|
10.94
|
11.01
|
|
Module Effiffifficiency
|
20.07%
|
20.93%
|
21.16%
|
|
Electrical data relates to standard test conditions(STC): irradiance 1000W/m ; AM1.5; cell temperature 25 2℃ measuring uncertainty of power is within ±3%. Certied in accordance with IEC61215,IEC61730-1/2 and UL1703.
|
|||
